Volsun Good Adhesion Thermally Conductive Tapes
- Detailed
Description
VS-TAP0501 is a high thermal conductivity tape made with a special formula and special process. It has good adhesion, heat resistance, and mechanical strength. It can achieve low interface thermal resistance under relatively low pressure. It is used between heat-generating power devices and heat dissipation aluminum sheets or housings to effectively exclude air, reduce air contact thermal resistance, and achieve effective filling effects. It can be used with materials such as copper, aluminum foil, conductive foam, and conductive cloth.
Features
- Operating temperature: -40℃~+120℃
- High thermal conductivity, low thermal resistance
- Excellent thermal conductivity and heat aging resistance
- Excellent flame retardant performance
- RoHS、REACH Environmental standards: RoHS, REACH
|
Item |
Typical Data |
Test Method |
|
Standard color |
White |
/ |
|
Thickness（mm） |
0.2mm |
ASTM D374 |
|
Flame retardant grade |
VTM-0 |
UL94 |
|
Breakdown voltage |
＞1200Vac |
ASTM D149 |
|
Thermal conductivity (W/m·k) |
0.5 |
ASTM D5470 |
|
180° Peel strength |
>1200 g/inch (Instant bonding to stainless steel plates) |
ASTM D412 |
Storage conditions & Specifications
- Temperature: 15℃-35℃
- Humidity: 0~68%RH
- Shelf life: 6 months in packaging
Specifications: support customization
